Endura Pro LED Batten 4 Feet 48W
Wattage: 36W/42W/48W
Max Lumens: 6240LM
CCT: 3000K/4000K/5000K
Features & Benefits
- Corrosion-Resistant and Impact-Proof Construction
- Selectable Wattage & CCT Up to 130 lm/W and 6,240 lumens.
- 0–10V Dimming and 110° Beam Angle
- Backed by 50,000 lifespan
Performance Data
| 3000K (≥80 CRI) | 4000K (≥80 CRI) | 5000K (≥80 CRI) | ||||||
|---|---|---|---|---|---|---|---|---|
| Model Number | Wattages | Input Current | Lumens | Efficacy | Lumens | Efficacy | Lumens | Efficacy |
| HL-VT-MW-MCCT-48W-4 Feet | 36W/42W/48W | 0.315A/0.369A/0.421A | 4680lm | 130 lm/W | 5460lm | 130 lm/W | 6240lm | 130 lm/W |
Product Summary
For Battery Rooms, Freezers, Garages, and Outdoor Under Canopy Applications. Available in Selectable Wattage & CCT- 36W/42W/48W.
Endura Pro LED Vapor Tight Strip is engineered for long-term reliability, corrosion resistance, and impact resistance. A polycarbonate housing with an opal diffuser cover seals out moisture and contaminants, making it a trusted choice for battery rooms, chilling plants, underground parking, garages, freezers, coolers, and outdoor under-canopy applications. With a 50,000-hour rated life, it is built to deliver reliable performance with less maintenance over time.
Applications:
Battery rooms, Chilling plants, Underground parkings, Garage, Freezers, Coolers and Outdoor Under Canopy.
Product Specification
Efficacy
130 lm/W
CCT Options
3000K / 4000K / 5000K
CRI
≥80
Beam Angle
110°
Input Voltage
120-277Vac
Power Factor (PF)
0.95
THD
≤20%
Dimming
0-10V standard
Operating Temp.
-20℃ to +35℃
Warranty
5 Years
Finish
Grey
Mounting
Surface & Suspended
Housing Material
Polly Carbonate
Lens Type
No Lens
FAQ
Frequently Asked Questions (FAQ's)
Do LED battens get hot?
LED battens do not get excessively hot. They generate far less heat than traditional tube lights and are designed with efficient heat dissipation, allowing them to remain cool to the touch during normal operation and operate safely for extended periods.
What safety tips should I follow during installation?
Use insulated tools, avoid installing in wet conditions, secure loose wiring, and ensure all connections are tight. If unsure, hire a qualified electrician.
What type of power supply is required for this LED batten?
The Endura Pro LED Batten operates on standard AC mains power. It does not require an external driver, starter, or ballast, as the LED driver is built into the fixture.
Do I need a starter for an LED batten?
No, LED battens have an inbuilt driver and do not require a starter or ballast.
Is it safe to install LED battens on ceilings?
Yes, they are designed for safe ceiling and wall surface mounting.
